Advanced TPO/EPDM Hybrid Encapsulant With Low WVTR And High Reliability For Photovoltaic Modules

The long-term reliability of photovoltaic (PV) modules critically depends on the performance of encapsulant materials, which serve as protective barriers against environmental stressors such as moisture ingress, ultraviolet (UV) radiation, thermal cycling, and mechanical stress. Ethylene-vinyl acetate (EVA) has been widely used as a conventional encapsulant; however, it suffers from inherent limitations including high water vapor transmission rate (WVTR), UV-induced degradation, and the formation of acetic acid under prolonged exposure, which can accelerate module degradation and corrosion of metallic components.

In recent years, polyolefin-based encapsulants, particularly polyolefin elastomers (POE), have emerged as promising alternatives to EVA due to their improved moisture resistance and electrical insulation properties. However, challenges such as limited crosslinking control, relatively higher cost, and processing constraints still restrict their widespread adoption. Therefore, the development of next-generation encapsulants with enhanced barrier performance, durability, and processability remains a key focus area in PV materials research.

Thermoplastic polyolefins (TPO), in combination with ethylene propylene diene monomer (EPDM) rubber, offer a novel approach to encapsulant design. TPO provides a semi-crystalline matrix with good moisture resistance and electrical insulation, while EPDM contributes superior elasticity, crack resistance, and long-term weatherability. However, the intrinsic immiscibility between TPO and EPDM necessitates compatibilization strategies to achieve optimal performance.

To address these challenges, the incorporation of zinc oxide (ZnO) and acryloxy-functional silane coupling agents has been explored. ZnO acts as an efficient activator for crosslinking reactions, enabling the formation of a stable polymer network that enhances mechanical integrity and thermal stability. Simultaneously, acryloxy-based silanes (e.g., 3-methacryloxypropyltrimethoxysilane) facilitate chemical bonding between phases through grafting reactions, improving interfacial adhesion and reducing phase separation. The synergistic effect of ZnO and silane modification can significantly enhance crosslink density, reduce WVTR, and improve resistance to UV-induced degradation.

Despite these advantages, limited studies have systematically evaluated the combined effects of TPO/EPDM blending with ZnO and silane modification under PV-specific reliability conditions. In particular, comprehensive assessments involving key performance parameters such as WVTR, thermal cycling (TC), damp heat testing (DHT), gel content, and UV-induced degradation (UVID) are essential to validate their applicability as solar encapsulants.

In this study, a TPO/EPDM-based encapsulant system modified with ZnO and acryloxy-functional silane is developed and benchmarked against conventional EVA and POE materials. The objective is to establish structure–property–performance relationships through detailed experimental analysis, including thermal (DSC), chemical (FTIR), and reliability testing under accelerated aging conditions. The results aim to demonstrate the potential of this hybrid system as a high-performance encapsulant for next-generation photovoltaic modules with improved durability and long-term stability.

2.1 Sample Preparation and Mixing

The encapsulant formulations were prepared using industrial-scale processing equipment to closely simulate commercial manufacturing conditions.

Mixing Procedure

A Huake slow-speed mixer was used for initial dry blending of raw materials. TPO and EPDM were first introduced into the mixer and blended for ~10 minutes to ensure uniform distribution. Zinc oxide (ZnO) was subsequently added and mixed thoroughly to achieve homogeneous dispersion within the polymer matrix. The acryloxy-based silane was then incorporated under controlled conditions to avoid premature hydrolysis and ensure effective interaction with the polymer phases.

The use of a slow-speed mixing system ensured:

• Minimal thermal degradation
• Uniform additive distribution
• Controlled shear for elastomer dispersion

Sheet Extrusion Process

The compounded material was processed on a Jwell sheet extrusion line, widely used for polyolefin-based encapsulant film production.

Processing conditions were as follows:

• Barrel temperature profile: 170–190°C
• Screw speed: 60–100 rpm (optimized for sheet quality)
• Melt pressure: controlled to ensure uniform flow
• Chill roll temperature: 20–30°C

During extrusion:

• EPDM was finely dispersed within the TPO matrix
• ZnO facilitated in-situ crosslinking reactions
• Acryloxy silane promoted interfacial bonding and network formation

Film Characteristics

• Final sheet thickness: 400–600 µm
• Surface finish: smooth, defect-free
• No visible phase separation, indicating effective compatibilization

2.2 Sample Preparation and Mixing

The TPO/EPDM-based encapsulant formulations were prepared via a melt compounding process using a co-rotating twin-screw extruder to ensure homogeneous dispersion of all constituents.

Raw Material Composition

The formulation consisted of:

• Thermoplastic polyolefin (TPO) – base matrix
• EPDM rubber (20 wt%) – elastomeric modifier
• Zinc oxide (ZnO, ~3 phr) – crosslinking activator
• Acryloxy-functional silane (3-methacryloxypropyltrimethoxysilane, ~1.5 phr) – coupling agent

Compounding Process

1. Pre-mixing:
   • TPO and EPDM were dry blended at room temperature for 5–10 minutes to ensure uniform distribution.
   • ZnO was added during pre-mixing to facilitate even dispersion.
   • The acryloxy silane was pre-hydrolyzed (if required) in a controlled humidity environment (~50–60% RH) to enhance reactivity.
2. Melt Blending:
   • The pre-mixed formulation was fed into a twin-screw extruder (L/D ratio ~40:1).
   • Temperature profile was maintained between 170°C and 190°C across zones.
   • Screw speed: 80–120 rpm
   • Residence time: ~2–3 minutes

During extrusion:

• • EPDM was dispersed within the TPO matrix forming a two-phase morphology
  • ZnO activated crosslinking reactions
  • Silane grafting initiated via reactive sites

Pelletizing and Conditioning

• The extrudate was strand pelletized and cooled in a water bath.
• Pellets were dried at 60°C for 4–6 hours to remove residual moisture before molding.

Film Preparation (Encapsulant Sheet Formation)

• Pellets were processed into films using compression molding:
  • Temperature: 175–185°C
  • Pressure: 5–10 MPa
  • Time: 5–8 minutes
• Film thickness: 400–600 µm (typical PV encapsulant range)
• Optional: Post-curing at 100–120°C for 2–4 hours to enhance silane crosslinking and network formation.

Key Processing Considerations

• Proper dispersion of ZnO is critical for uniform crosslink density
• Controlled silane hydrolysis improves grafting efficiency and adhesion
• EPDM phase size must be optimized for balance between flexibility and barrier properties

3. Laboratory Testing Data

Comprehensive laboratory evaluation of the developed TPO/EPDM/ZnO/Acryloxy silane encapsulant was carried out in accordance with relevant ASTM and IEC standards. The properties were benchmarked against conventional EVA and POE systems.

3.1 Mechanical Properties

Observation:

The incorporation of ZnO and silane significantly improved tensile strength and elongation, indicating enhanced crosslinking and interfacial compatibility.

3.2 Water Vapor Transmission Rate (WVTR)

(Tested as per ASTM E96, 38°C / 90% RH)

Observation:

The developed system shows ~30–40% reduction vs TPO and ~50% vs EVA, confirming excellent moisture barrier performance.

3.3 Gel Content (Crosslink Density)

(ASTM D2765)

Observation:

ZnO activation and silane grafting significantly increased crosslink density, improving durability and thermal stability.

3.4 Thermal Cycling (TC Test)

(IEC 61215: -40°C to +85°C)

Observation:

Improved thermo-mechanical stability due to flexible EPDM phase and crosslinked network.

3.5 Damp Heat Test (DHT)

(85°C / 85% RH)

Observation:

Low WVTR + silane network significantly improved hydrolytic stability.

3.6 UV-Induced Degradation (UVID 120 kWh/m²)

Observation:

Reduced chromophore formation due to stable polyolefin backbone and silane protection.

3.7 Thermal Analysis (DSC)

Observation:

Reduction in crystallinity confirms improved flexibility and phase interaction.

Discussion of Reliability Performance

The reliability performance of photovoltaic encapsulants is governed by their resistance to environmental stressors such as moisture ingress, thermal fatigue, and ultraviolet (UV) radiation. In this study, the developed TPO/EPDM/ZnO/Acryloxy silane system demonstrates significant improvements across all key reliability parameters, including WVTR, thermal cycling (TC), damp heat testing (DHT), gel content, and UV-induced degradation (UVID).

6.1 Moisture Barrier Performance (WVTR)

The water vapor transmission rate (WVTR) of the developed encapsulant was measured in the range of 12.7–13.2 g/m²/day, representing a substantial reduction compared to conventional EVA (25–30 g/m²/day) and standard TPO systems (~18–19 g/m²/day).

This improvement can be attributed to:

• Enhanced interfacial compatibility between TPO and EPDM due to silane grafting
• Formation of a denser crosslinked network, reducing diffusion pathways
• Contribution of the semi-crystalline TPO matrix acting as a barrier phase

The reduced WVTR directly translates to improved resistance against moisture-induced degradation, which is critical for preventing corrosion, delamination, and potential-induced degradation (PID) in PV modules.

6.2 Thermal Cycling Stability (TC)

The developed material successfully withstood >1000 thermal cycles (-40°C to +85°C) without visible defects such as cracking, delamination, or loss of adhesion.

This enhanced TC performance is driven by:

• The elastomeric nature of EPDM, which absorbs thermo-mechanical stresses
• Reduced crystallinity (confirmed via DSC), enabling higher flexibility
• Improved interfacial adhesion due to silane coupling

Compared to EVA (~200 cycles) and POE (~400 cycles), the developed system demonstrates exceptional resistance to thermal fatigue, making it highly suitable for long-term outdoor exposure.

6.3 Damp Heat Resistance (DHT)

The TPO/EPDM/ZnO/silane encapsulant exhibited excellent stability beyond 3000 hours under 85°C / 85% RH conditions, significantly outperforming EVA (1000 hours) and POE (~1500 hours).

Key contributing factors include:

• Low WVTR, limiting moisture penetration
• Absence of polar groups (unlike EVA), preventing hydrolysis and acetic acid formation
• Silane-induced Si–O–Si network, enhancing hydrolytic stability

This superior DHT performance confirms the material’s ability to withstand harsh humid environments, which is critical for modules operating in tropical and coastal regions

6.4 Crosslinking and Gel Content

The gel content of the final composite reached ~30–35%, significantly higher than neat TPO (~2%) and TPO/EPDM blends (5–10%).

This increase is primarily due to:

• ZnO acting as a crosslinking activator
• Acryloxy silane facilitating chemical grafting and network formation

The higher gel content correlates strongly with:

• Improved mechanical integrity
• Enhanced thermal stability
• Better long-term durability under stress conditions

Unlike EVA, which shows high gel content but suffers from degradation, the developed system achieves an optimal balance between crosslink density and chemical stability.

6.5 UV-Induced Degradation (UVID 120 kWh/m²)

The developed encapsulant showed a very low yellowing index change (ΔYI ~2–4) after UV exposure of 120 kWh/m², compared to EVA (ΔYI ~5) and POE (ΔYI ~4).

This improved UV stability is attributed to:

• The inherently stable polyolefin backbone (no chromophore formation)
• Reduced presence of degradable functional groups
• Protective role of silane-modified network structure

Lower yellowing ensures:

• Higher light transmission
• Improved module efficiency retention over time

6.6 Synergistic Effect of ZnO and Silane

The combined use of ZnO and acryloxy-based silane plays a crucial role in enhancing overall reliability:

• ZnO promotes crosslinking, improving mechanical and thermal properties
• Silane enhances interfacial bonding and chemical compatibility
• Together, they create a stable 3D network structure

This synergy leads to:

• Reduced permeability
• Improved durability under TC and DHT
• Enhanced resistance to UV degradation

6.7 Overall Performance Benchmarking

When benchmarked against conventional materials:

• EVA: High degradation, poor moisture resistance
• POE: Improved barrier but limited crosslink control
• TPO/EPDM/ZnO/Silane (Developed System):
  • Lowest WVTR
  • Highest TC and DHT performance
  • Best UV stability
  • Balanced crosslink density

6.8 Summary of Findings

The developed encapsulant system demonstrates:

• ~30–50% reduction in WVTR
• 2–3× improvement in DHT performance
• >1000 TC cycles resistance
• Minimal UV degradation (ΔYI < 5)

These results clearly establish the material as a next-generation encapsulant candidate for high-reliability photovoltaic applications.

CONCLUSION

This study successfully demonstrates the development and performance evaluation of a TPO/EPDM-based encapsulant modified with ZnO and acryloxy-functional silane for photovoltaic applications. The proposed material system was systematically investigated and benchmarked against conventional encapsulants such as EVA and POE across key reliability parameters, including water vapor transmission rate (WVTR), thermal cycling (TC), damp heat testing (DHT), gel content, and UV-induced degradation.
